CM-T335 - TI AM335x Computer-on-Module | System-on-Module

ARM Cortex-A8 SoM starting from $27

  • Optimized for industrial embedded applications
  • Miniature size and power efficiency
  • Ideal solution for cost-sensitive systems

AM335x processor

Texas Instruments Sitara AM335x processor family

  • ARM Cortex-A8 CPU, 600MHz
  • PowerVR SGX530 GPU
  • NEON SIMD and VFPv3
  • SoM Highlights

    Feature Highlights

  • Up to 512MB DDR3 and 1GB NAND
  • LCD interface, up to 1366 x 768
  • 1000Mbps Ethernet, 4x USB, 5x UART, 70x GPIO, 2x CAN
  • WiFi 802.11b/g/n and Bluetooth 4.0
  • View full spec

    SW support

    Linux, Android and Windows CE

  • Full Board Support Packages and ready-to-run images
  • Comprehensive software development documentation
  • Mainline Linux kernel support
  • Why choose CompuLab?

    10-years Longevity

    Direct Support by Engineers

    Mainline Linux and Yocto

    In-House Manufacturing

    Industrial Temperature

    Configure-to-Order

    Learn more about CompuLab advantages.

    • "Option" column specifies the configuration code required to have the particular feature.
    • "+" means that the feature is always available

    CPU Core and Graphics

    CPUTexas Instruments AM3352 CPU, 300MHz
    32KB (L1) + 256KB (L2) cache
    C300
    Texas Instruments AM3354 CPU, 600MHz
    32KB (L1) + 256KB (L2) cache
    C600G
    Graphics
    Acceleration
    Unit
    PowerVR SGX530 GPU providing 2D / 3D graphics acceleration with OpenGL-ES and OpenVG support.
    C600G

    Memory and Storage

    RAM128MB – 512MB, DDR3-1066, 16-bit bus width
    D
    StorageOn-board NAND flash disk, 128MB - 1GB, 8bit, SLC
    N

    Display

    DisplayParallel 24-bit display interface - up to 1366 x 768
    +
    Touchscreen4/5/8-wire resistive touch-screen support
    +
    Capacitive touch-screen support through I2C interface
    +

    Network

    Gigabit Ethernet1000Base-T Ethernet interface implemented with AM335x integrated MAC and the Atheros AR8033 RGMII PHY
    E
    WiFiWiFi 802.11b/g/n implemented with TI WL1271 chipset
    WB
    BluetoothBluetooth 4.0 (low energy)
    WB

    Audio

    Analog AudioAudio codec with analog stereo output, stereo input and electret microphone support
    A
    Digital AudioI2S compliant digital audio interface
    A

    I/O

    USBUSB2.0 OTG high-speed port, 480 Mbps
    U1
    4x USB2.0 host high-speed ports, 480 Mbps (precludes OTG mode)
    U4
    Serial Ports
    (UARTs)
    Up to 5 UART ports, TIA/EIA-232-F compatible, 3.3V interface, up to 5.0 Mbps
    +
    CAN busUp to 2 CAN bus interfaces, 3.3V levels
    +
    MMC/SD/SDIOUp to 2 MMC/SD/SDIO interfaces, support for HC MMC and SDHC up to 32GB
    +
    SPIUp to 2 configurable SPI bus interfaces (Slave/Master modes)
    +
    I2CUp to 2 I2C interfaces (up to 400Kbps)
    +
    GPIOUp to 70 multifunction signals. Can be used as GPIO (shared with other functions)
    +
    ADCUp to 8 general-purpose ADC channels
    +

    System Logic

    RTCReal time clock, powered by external lithium battery
    +

    Electrical Specifications

    Supply Voltage
    Single 3.3V DC
    Digital I/O voltage3.3V
    Active power consumption0.5 - 1.5 W, depending on configuration and CPU frequency

    Mechanical Specifications

    Dimensions68 x 30 x 5 mm
    Weight15 gram
    Connectors204-pin SO-DIMM edge connector

    Environmental and Reliability

    MTTF> 200,000 hours
    Operation temperature (case)Commercial: 0° to 70° C
    Extended: -20° to 70° C
    Industrial: -40° to 85° C. Click for availability note
    Storage temperature-40° to 85° C
    Relative humidity10% to 90% (operation)
    05% to 95% (storage)
    Shock50G / 20 ms
    Vibration20G / 0 - 600 Hz
    CM-T335 (TI AM335x) block diagram

    CM-T335 and SBC-T335 Evaluation Kit

    Package contents

    Technical Support

    • Technical support for 12 months.
    • Schematics review of the customer's carrier board design.
    • LCD panel compatibility verification and driver adaptation service.
    • 45-day trial period. Eval Kit will be accepted for refund if the user finds the product not suitable for his needs.

    Hardware

    Kit Price: $365

    • CM-T335-D512-C600G-N512-E-A-U4-WB
    • CM-T335-D256-C300-N512-E-A-U1
    • SB-T335-EVK
    • WiFi antenna and cable
    • Serial port cable
    • HDMI to DVI cable
    • USB cable and adapter
    • LCD panel
    • Adapters & cables for generic LCD panel interface
    • 12V power supply

    Documents and Guides

    Product status: Active

    CompuLab part number specifies all options available for a particular product.
    P/N template: CM-T335-Dx-Cx-Nx-[E]-[A]-[Ux]-[WB]-[Tx]

    Minimal Configuration

    Minimal configuration P/N: CM-T335-D128-C300-N128-U1
    1K-unit price:
    $ 27

    Optional Features

    FeatureOptionsP/N codeAdd ($)
    DRAM size128MB
    256MB
    512MB
    D128
    D256
    D512
    -
    1
    4
    CPU type300MHz, no GPU
    600MHz, with GPU
    C300
    C600G
    -
    7
    NAND flash (SLC)128MB
    512MB
    1GB
    N128
    N512
    N1G
    -
    10
    12
    Ethernet portsNo
    Yes
    -
    E
    -
    3
    AudioNo
    Yes
    -
    A
    -
    3.5
    USB ports1
    4
    U1
    U4
    -
    3.5
    WiFi & BluetoothNo
    Yes
    -
    WB
    -
    20
    Temperature rangeCommercial
    Extended Tested
    Industrial Certified
    Industrial Tested
    -
    TET
    TIC
    TIT
    -
    15
    10
    50
    Software PreloadingNo
    Yes
    -
    X
    -
    $1/100MB
    • Prices are specified in U.S. Dollars. Prices are periodically updated according to variations in component costs. Prices are subject to change without advance notice.

    Small Quantity Orders

    Pricing is specified for 1000-unit orders. In order to calculate the price for another quantity, multiply the unit price (with selected options) by the factor listed in the table below:

    QTY Factor
    1K 1.0
    5001.2
    1001.5
    102.0
    12.5
